21
4.5.1 HDD
Information
Here is to list hard disk type, total space, free space, and status. See Figure 4-8.
For 32 series product there are max 2 HDDs. For 38 series product there are max 8 HDDs.
○ means current HDD is normal.. - means there is no HDD.
If disk is damaged, system shows as “?”. Please remove the broken hard disk before you add a
new one.
Figure 4-8
In Figure 4-8, click view record d time button, HDD record time information interface is shown as
in Figure 4-9.
Figure 4-9
Parameter Function
SATA 1-4 here means there are 4 HDDS.
For 32 series product there are max 2 HDDs. For 38 series product there
are max 8 HDDs.
When HDD is working properly, system is shown as O. . “_” means there is
no HDD.
SN You can view the HDD amount the device connected to;
﹡ means the second HDD is current working HDD.
