IC Realtime 8/16/32 Channel 1.5U 8/16 PoE Network Video Recorder - Manual (Page 11)

3
6-ch alarm output
Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output））
Including one controllable DC +12V output.
4 built-in SATA ports.
Storage
1 peripheral eSATA port
RS232 Port
(RS-422)
One RS232 port to debug transparent COM data.
RS485 port
(RS-485)
One RS485 port to control PTZ. Support various protocols.
USB2.0 Port 3 peripheral USB2.0 ports.
Network
Connection
One RJ45 10/100M/1000Mbps self-adaptive Ethernet port.
Power Port One power port. AC100～240V 50+2% Hz
Power Button One power button in the rear panel.
Power On-off
Button
One power on-off button in the front panel.
IR Remote
Control
Receiver
Support IR remote control
Clock Built-in clock.
Indication Light
z 16 record status indication lights
z One system running status indication light.
z One remote control button indication light.
Power
Consumption
＜ 40W(Exclude HDD)
Working
Temperature
0℃～+50℃
Working
Humidity
10℅－90℅
Air pressure 86kpa－106kpa
Dimension 440mm × 407mm × 70mm
Weight 5kg～6kg（Exclude HDD）
Installation Desk installation
