9

Figure 2-5

2.4.2 PC-end to the device-end

Device Connection
Connect the speaker or the pickup to the audio output port in the PC and then connect the
earphone or the sound box to the first audio input port in the device rear panel.
Login the Web and then enable the corresponding channel real-time monitor.
Please refer to the above interface (Figure 2-4) to enable bidirectional talk.
Listening Operation
At the PC-end, speak via the speaker or the pickup, and then you can get the audio from the
earphone or sound box at the device-end. See Figure 2-6.

Figure 2-6

2.5 Mouse Operation

Please refer to the following sheet for mouse operation instruction.

When you have selected one menu item, left click mouse to view menu
content.
Modify checkbox or motion detection status.

Left click
mouse

Click combo box to pop up dropdown list
