INTRODUCTION INTRODUCTION
Thank you for purchasing the Heli-Max Digital Pitch Gauge. This
product is intended to measure the angle on the helicopter’s main
and tail rotor blades during setup. The gauge can also be used
without the mounting plate for other tasks that would require a level.
®
CONTROLS CONTROLS
1
2
3
4
5
6
7 8 9
10
11
12
1. Ruler
2. Blade Clamp
3. Mounting Plate
4. Digital Pitch Gauge
5. ABS Indicator
6. REL Indicator
7. ON/OFF
8. HOLD Button
9. ZERO Button
10. LCD Display
11. Hold Indicator
12. Battery Compartment Cover
