Haltech E6K User Manual
Page 80
74
SECTION 4
E6K Inputs & Outputs
The E6K has several types of optional inputs and outputs. These are:
-
Idle Speed Control
-
O
2
Closed Loop Control
-
Auxiliary In (Aux In)
-
Auxiliary Out (Aux Out)
-
Digital Output (Digital Out 1-2)
-
Pulse Width Modulated Output (PWM 1-4)
Every output except the Digital Outputs are available all the time – irrespective of the engine
configuration. Idle Speed and O
2
Closed Loop Control are not general purpose outputs – they
can only be used for the stated purpose. Aux Out, Digital Out 1-2, and PWM 1-4 are general
purpose outputs – they can be selected to control any devices from a list of options.
Depending on whether or not the ECU is operated in the Advanced mode, the Digital Outputs
may or may not be available. If they are not available, then this is because the configuration
you have chosen has consumed all of the output lines from the microprocessor. This means
you are limited to the 4 x PWM outputs and the Auxiliary Output to control output devices. If
you are operating the ECU in Basic mode, then you will have up to 2 Digital Outputs
available, depending on your configuration.
Below is a summary of the general purpose outputs and the options list they contain:
General Purpose Outputs
Output Description
Aux Out
Digital Out 1–2
PWM 1 – 4
Turbo Wastegate
NO
NO
•
Bypass Air Control (BAC)
NO
NO
•
Dual Intake Valve
NO
•
•
Torque Convertor Control
NO
•
•
Thermofan
NO
•
•
Intercooler Fan
NO
•
•
Shift Light
NO
•
•
Aux Fuel Pump
NO
•
•
Stall Saver
NO
•
•
Staging Signal
•
•
•
Turbo Timer
NO
•
•
NOS Switch
NO
•
•
Anti-Lag Switch
NO
•
•
Ignition Bypass
•
NO
NO
Tacho Output
•
NO
NO
Ignition Toggle
•
NO
NO
