GTCO CR 1212 - Users Guide User Manual
Page 15
CR 1212 15
*Output for Bit Pad One or Two configurations using absolute coordinates.
**Output for Bit Pad One or Two configurations using relative coordinates.
Sx and Sy are the X and Y coordinate signs. 1 is positive and 0 is negative.
PR is the proximity bit. 0 is in-prox and 1 is out-of-prox.
PH is the phasing bit, which is always 1.
X0, X1, etc. and Y0, Y1, etc. are the X and Y coordinate bits.
