Summagrid IV 15
1.16 Resolution Commands: Variable Resolution
1.16.1 Description
The Variable Resolution command is used to define the resolution of each axis
independently. It allows the user to set the resolution to any whole number from
0001 to 2540.
1.16.2 When to Use
Variable Resolution is used to match the tablet resolution to that of a graphics
terminal. The resolution of a graphics terminal is measured in pixels, a unit of
measurement similar to counts. Therefore, to match the measurement system of
the graphics terminal (pixels) to that of the tablet (inches), the Summagrid IV
automatically changes the report format of the tablet to counts.
1.16.3 Command Syntax
Variable Resolution
X Axis
Y Axis
a=X
bbbb=ASCII value from 0001 to 2540 lpi
a=Y
bbbb=ASCII value from 0001 to 2540 lpi
1.17 Resolution Commands: Confirm Resolution
1.17.1 Description
The Confirm Resolution command is used to send a report to the host that specifies
the maximum X and Y values at the current resolution setting. When the user sends
a Confirm Resolution command, the tablet dimensions are multiplied by the
resolution and the results are sent to the host in the data format previously
selected.
1.17.2 When to Use
Use this command to verify a Variable Resolution setting.
1.17.3 Command Syntax
Confirm Resolution
