4
Two-Stroke Option
o
O .S . 46 AX two-stroke engine (OSMG0547)
o
O .S . Muffler Extension #873 (for 46AX engine
using a standard muffler) (OSMG2578)
OR
o
J’Tec JT-601 In-Cowl universal inverted muffler
(scale muffler) (JTCG7015)
Four-Stroke Option
o
O .S . FL-70 RC four-stroke engine (OSMG0876)
Electric Motor Option & Required Parts
o
ElectriFly
™
RimFire
™
.55 (42-60-480) Brushless
Outrunner motor (GPMG4715)
o
ElectriFly Medium Motor Mount (GPMG1255)
o
ElectriFly Silver Series 60A Brushless ESC
(GPMM1850)
o
APC 13 x 10 E-Prop (APCQ4140)
o
(2) Great Planes ElectriFly 11 .1V, 3200mAh 20C
LiPo BP Series (GPMP0727)
OR
o
(2) Great Planes ElectriFly 11 .1V, 3350mAh 25C
LiPo Power Series (GPMP0541)
o
Deans
®
Series 2 Male Ultra
®
adapter (GPMM3143)
o
6" [150mm] servo extension (for ESC signal lead)
(HCAM2701)
o
PolyCharge4
™
LiPo battery charger (GPMM3015)
o
Equinox
™
1-5 cell LiPo cell balancer (GPMM3160)
o
12 Volt DC power supply (HCAP0250) (optional)
o
RC Electronics Watt’s Up Watt Meter
(RELP0100) (optional)
Radio System Recommendations
o
4 channel radio system
o
(4) Futaba
®
S3004 Standard Ball Bearing Servo
(FUTM0004)
o
Futaba NR4J 4 .8V 600mAh Receiver Battery
(FUTM1280)
o
(2) 12" [300mm] servo extension (HCAM2711 for
Futaba)
o
6" Y-harness (FUTM4130)
o
J-Series Switch w/ Charge Plug (FUTM4370)
o
Switch & Charge Jack Mounting Set (GPMM1000)
o
Servo Mounting Screws (Set of 10) (FUTM2550)
ADDITIONAL ITEMS REQUIRED
To finish this airplane you will need the following items .
Adhesives and Building Supplies
o
3/8" x 3" Heat Shrink Tubing (GPMM1060)
o
R/C foam rubber 1/4" [6mm] thick (HCAQ1000)
o
Drill bits: 1/16" [1 .6mm], 5/64" [2mm], #48
o
1 oz . [30g] Medium Pro
™
CA+ (GPMR6008)
o
1 oz . [30g] Thin Pro CA (GPMR6002)
o
1 oz . [30g] Thin Foam-Safe CA (HOTR1040)
o
CA applicator tips (HCAR3780)
o
CA debonder (GPMR6039)
o
Pro 30-minute epoxy (GPMR6047)
o
Epoxy brushes (6, GPMR8060)
o
Mixing sticks (50, GPMR8055)
o
Mixing cups (GPMR8056)
o
Threadlocker
™
thread-locking compound
(GPMR6060)
o
Panel Line Pen (TOPQ2510)
o
#64 rubber bands (1/4 lb [113g] box, HCAQ2020)
o
18" flexible steel rule (HCAR0460)
o
Hobbico Retractable Fabric Tape Measure
(HCAR0478)
o
6-32 tap and drill set (GPMR8102)
o
Tap handle (GPMR8120)
o
Pliers with wire cutter (HCAR0625)
o
Hobbico Heavy Duty Diagonal Cutter 7" (HCAR0627)
o
electric drill
o
Hobbico ball-end hex wrench set – metric
(HCAR0521)
o
Hobbico ball-end hex wrench set – SAE (HCAR0520)
o
(2) 1" [25mm] C-Clamps
o
Excel Small Clamp (EXLR5663)
o
Zona L-Square (ZONR3734)
o
Medium T-pins (100, HCAR5150)
o
Easy-Touch
™
Bar Sander 5 .5" (GPMR6169)
o
Sandpaper assortment
o
Masking tape (TOPR8018)
o
Electrical tape
o
Toothpicks, round
o
Denatured alcohol (for epoxy clean up)
Optional Supplies and Tools
o
21
st
Century
®
sealing iron (COVR2700)
o
21
st
Century iron cover (COVR2702)
o
Rotary tool such as Dremel
®
o
Rotary tool reinforced cut-off wheel (GPMR8200)
o
Hobbico Z-bend pliers (HCAR2000)
