1. Install the pushrods and guide tubes into the
fuselage, but do not glue them into position until instructed
to do so. The pushrods cross inside the fuselage.
Refer to this sketch and the photo for the following
two steps. ❏
2. Fit the servos into the balsa servo trays (14). Drill
1/16" holes through the trays, then mount the servos to the
trays with the screws that came with the servos.
❏
3. Fit the servo trays with the servos into the crutch. Do
not glue the servo trays to the crutch until instructed to do
so. Connect the pushrods to the servos. If the pushrods do
not align with the servos, cut slots in the landing gear former
that will allow the pushrods to align as shown in the photo
and in the sketch.
Install the Servos
18
