5. You must test the operation of the model before every
flight to insure all equipment is operating, and you must
make certain the model has remained structurally sound.
Be sure to check clevises or other connectors often and
replace them if they show signs of wear or fatigue.
NOTE: We, as the kit manufacturer, provide you with a top
quality kit and great instructions, but ultimately the quality of
your finished model depends on how you build it; therefore,
we cannot in any way guarantee the performance of your
completed model, and no representations are expressed or
implied as to the performance or safety of your completed
model arirplane.
Remember: Take your time and follow directions to end
up with a well-built model that is straight and true.
Please inspect all parts carefully before starting to build!
If any parts are missing, broken or defective, or if you
have any questions about building or flying this
airplane, please call us at (217) 398-8970. If you are
calling for replacement parts, please reference the part
numbers and the kit identification number (stamped on
the end of the carton) and have them ready when calling.
We can also be reached by E-Mail at:
[email protected]
DECISIONS YOU MUST MAKE
Engine Selection
There are several engines that will work well in your
Dazzler 40. We recommend a hot 2-stroke such as an
O.S.
® .40FX or SuperTigre ™ G45. For unsurpassed
power and realistic sound, an O.S. FS-52 Surpass ™
4-stroke can’t be beat. The engine you select will
determine how you build the firewall section, so it is
important that you have the engine close at hand while
building.
PREPARATIONS
Required Accessories
Items in parentheses (GPMQ4243) are suggested part
numbers recognized by distributors and hobby shops and
are listed for your ordering convenience. GPM is the Great
Planes brand, TOP is the Top Flite
® brand, and HCA is the
Hobbico ® brand.
❏
Four-channel radio with five servos
❏
Engine – See Engine Selection above
❏
Propeller (Top Flite ® Power Point ™ ); Refer to your
engine’s instructions for proper size
❏
Fuel tank 6 oz. (SULQ1426)
❏
Medium fuel tubing (GPMQ4131)
❏
2-1/2" Main wheels (DUBQ0875)
❏
1" Tailwheel (GPMQ4241)
❏
Top Flite MonoKote ® (2 to 3 rolls)
❏
1/4" Latex foam rubber padding (HCAQ1000)
❏
Switch and Charge Jack (GPMM1000)
❏
(4) 4-40 Blind Nuts (GPMQ3324)
❏
Engine Mount .20 to .48 (GPMG1041)
❏
(4) 4-40 x 1" Machine Screws (GPMQ3016)
❏
24" Flex Cable Pushrod (GPMQ3700)
Building Supplies and Tools
These are the building tools that are required. We
recommend Great Planes Pro
™ CA and Epoxy glue.
❏
2 oz. Pro CA (Thin, GPMR6003)
❏
2 oz. Pro CA+ (Medium, GPMR6009)
❏
6-Minute Pro Epoxy (GPMR6045)
❏
30-Minute Pro Epoxy (GPMR6047)
❏
Hand or electric drill
❏
Sealing iron (TOPR2100)
❏
Heat gun (TOPR2000)
❏
Hobby saw
❏
Hobby knife, #11 Blades (HCAR0311)
❏
Razor plane (Master Airscrew ® )
❏
Pliers (Common and Needle Nose)
❏
Screwdrivers (Phillips and flat tip)
❏
T-pins (HCAR5150)
❏
60" Retractable Tape Measure (HCAR0478)
❏
Straightedge with scale
❏
Masking tape (GPMR1010)
❏
Sandpaper (coarse, medium, fine grit)
❏
Easy-Touch ™ Bar Sander (or similar)
❏
Plan Protector (GPMR6167)
❏
Lightweight balsa filler such as Hobbico ® HobbyLite ™
(Hobbico HCAR3400)
❏
1/4-20 Tap and Drill (GPMR8105)
❏
Isopropyl rubbing alcohol (70%)
❏
Ballpoint pen
❏
90° Building square (HCAR0480)
❏
Canopy glue
❏
Drill bits: 1/16", 1/8", 5/32", 3/16", 1/4"
Optional Supplies and Tools
❏
CA Applicator Tips (HCAR3780)
❏
Epoxy brushes (GPMR8060)
❏
Epoxy mixing sticks (GPMR8055)
❏
CA Debonder (GPMR6039)
❏
Hot Sock ™ (TOPR2175)
❏
Single-edge razor blades (HCAR0312)
❏
Curved tip canopy scissors for trimming plastic parts
(DTXR1150)
❏
4 oz. Pro Wood Glue (GPMR6161)
