5. You must correctly install all R/C and other components
so that the model operates correctly on the ground and in
the air.

6. You must check the operation of the model before every
flight to insure that all equipment is operating and that the
model has remained structurally sound. Be sure to check
clevises or other connectors often and replace them if they
show any signs of wear or fatigue.

7. If you are not already an experienced R/C pilot, you
should fly the model only with the help of a competent,
experienced R/C pilot.

8. While this kit has been flight tested to exceed normal use,
if the plane will be used for extremely high stress flying,
such as racing, the modeler is responsible for taking steps
to reinforce the high stress points.

9.

WARNING: The cowl, wheel pants and wing struts

included in this kit are made of fiberglass, the fibers of which
may cause eye, skin and respiratory tract irritation. Never
blow into a part (wheel pant, cowl) to remove fiberglass
dust, as the dust will blow back into your eyes. Always wear
safety goggles, a particle mask and rubber gloves when
grinding, drilling and sanding fiberglass parts. Vacuum the
parts and the work area thoroughly after working with
fiberglass parts.

Remember: Take your time and follow the instructions to
end up with a well-built model that is straight and true.

If you have not flown this type of model before, we
recommend that you get the assistance of an experienced
pilot in your R/C club for your first flights. If you’re not a
member of a club, your local hobby shop has information
about clubs in your area whose membership includes
experienced pilots.

In addition to joining an R/C club, we strongly recommend you
join the AMA (Academy of Model Aeronautics). AMA
membership is required to fly at AMA sanctioned clubs. There
are over 2,500 AMA chartered clubs across the country.
Among other benefits, the AMA provides insurance to its
members who fly at sanctioned sites and events. Additionally,
training programs and instructors are available at AMA club
sites to help you get started the right way. Contact the AMA at
the address or toll-free phone number below:

Academy of Model Aeronautics

5151 East Memorial Drive

Muncie, IN 47302-9252

Tele. (800) 435-9262

Fax (765) 741-0057

Or via the Internet at: http://www.modelaircraft.org

This is the list of hardware and accessories required to finish the
Super Stearman. Order numbers are provided in parentheses.

Engine (refer to the engine size requirements on the

cover of the manual)

4-Channel radio
(1) standard servo (throttle)
(4) servos with minimum of 54 oz/in torque (2-ailerons,

1-elevator, 1-rudder)

(2) 12" [300mm] servo extensions (for aileron servos,

HCAM2711 for Futaba

®

)

(1) Y-harness (for aileron servos, HCAM2751 for Futaba)
(1) minimum 1,000mAh receiver battery

Propeller and spare propellers (refer to your engine

manufacturer's recommendations)

2' [600mm] large, silicone fuel tubing (GPMQ4133)

Optional: If building the Super Stearman with four aileron
servos, in addition to the items previously mentioned you
will also need two more aileron servos, two more servo
extensions and one more Y-harness.

In addition to common household tools and hobby tools, this
is the “short list” of the most important items required to
build the Super Stearman.

Great Planes Pro™ CA and

Epoxy glue are recommended.

R/C foam rubber (1/4" [6mm] - HCAQ1000, or 1/2"

[13mm] - HCAQ1050)

1 oz. [30g] Thin Pro CA (GPMR6002)

1 oz. [30g] Medium Pro CA+ (GPMR6008)

Pro 30-minute epoxy (GPMR6047)

Pro 6-minute epoxy (GPMR6045)

Drill bits: 1/16" [1.6mm], 5/64" [2mm], 3/32" [2.4mm],

1/8" [3.2mm], #29 or 9/64" [3.6mm], 3/16" [4.8mm],

❏ 3 pkgs

Stick-on segmented lead weights (GPMQ4485)

#1 Hobby knife (HCAR0105)

#11 blades (5-pack, HCAR0211)

Small T-pins (100, HCAR5100)

R/C-56 canopy glue (JOZR5007)

CA applicator tips (HCAR3780)

Denatured Alcohol (for epoxy cleanup)

Flat Black Fuelproof Paint (for cockpit)

8-32 Tap (GPMR8103)

8-32 Tap Handle (GPMR8120)

Adhesives and Building Supplies

Hardware and Accessories

ADDITIONAL ITEMS REQUIRED

NOTE: We, as the kit manufacturer, provide you with a top quality

kit and great instructions, but ultimately the quality of your

finished model depends on how you build it; therefore, we cannot

in any way guarantee the performance of your completed model,

and no representations are expressed or implied as to the

performance or safety of your completed model.

3
