PARTS & ASSEMBLY SHEET
For Customer Service, contact the place of purchase to arrange for replacement parts.
7. Slip Canopy loop collar (H) over the chain, then do the
same with the canopy (G).
8. When ready to complete the installation Use the other
chain connector and attach the other end of the chain to
the canopy loop (F) and close the chain connector.
9. Make sure the weight of the chandelier will be
supported by the chain-not the electrical wire.
* You may now install the fixture.
Fixture Name: Waverly 3500-M1L AB
Fig. 2 ASSEMBLING THE FIXTURE (Fig. 2)
3. Slide on the socket and secure it by threading
Socket Ring (R) onto the threaded socket until
tight.
4. Measure to determine the correct number of
links needed for the proper hanging height. Use a
pair of pliers to open one link of the Chain (K) then
remove and discard the excess chain.
5. Use Chain Connector (L) to attach one end of
the chain to the Top Loop (J) and close the chain
connector.
6. Feed the fixture wires through the Chain (every
three links) and pull the wires until taut.
7. Slip Canopy Loop Collar (H) over the chain. Then
do the same with the Canopy (G).
8. To complete the installation, use the other chain
connector to attach the other end of the chain to
Canopy Loop (F) and close the chain connector.
9. Make sure that the weight of the chandelier will
be supported by the chain, not the electrical wire.
* You may now install the fixture.
Note: Complete these remaining steps after the
fixture is hung.
10. Install the light bulb (not provided) in
accordance with the fixture's specifications.
(DO NOT EXCEED MAXIMUM WATTAGE RATING)
