PARTS & ASSEMBLY SHEET

Fixture Name: AUTUMN TWILIGHT 9903-3P

This fixture assembled PO:

Notice:

Date:

Please review the parts listing and check for all parts before assembling the fixture. If any parts are missing or

damaged, please note on this sheet and contact the place of purchase to arrange for replacement parts.

PARTS LIST

Canopy

1ea Φ135*H55 ㎜

Chain

1ea Φ3.8*6ft

Link

2ea W19*H54 ㎜

Crystal Leaf

45ea W22*H50 ㎜

Company Name:______________________Co Account#:__________

below to be filled out by retailer

Hex Nut

2ea NPS-1/4-18

Nipple

1ea NPS 1/4-18*75 ㎜

Mounting Strap

1ea W103*T2.0 ㎜

Bulbs

3ea Halogen,

Type G4 20W

Wire Connectors

3ea Orange

Canopy Loop

1ea NPS 1/4-18*H41 ㎜

Mounting Screws

2ea G8/32*H32 ㎜

Part Needed ______________________________

Comments

Quantity _________________________________

Reason why (missing, scratched, broken glass, bent, bad finish)

__________________________________________________________________________

9903-3P

Fig.3

FIXTURE ASSEMBLY INSTRUCTIONS

Read and review installation instruction sheet

before assembling the fixture

1. Open bag on the arm and carefully arrange the
bead strings.
2. Screw Crystal Leaf (A) on the arm. See the attached

Crystal installation diagram. Hold carefully by the metal base to

prevent the crystal from cracking.

3. Install the light bulbs in accordance with the
fixture's specification.

Bulb note: Use a tissue or paper towel to hold the
bulb and push down into socket. Oils or dirt can
cause the bulb life to shorten. Rubbing alcohol is
recommended to clean the bulbs if dirty.

(DO NOT EXCEED THE MAXIMUM WATTAGE RATING!)

For Customer Service, contact the place of purchase to arrange for replacement parts.
