Golden Lighting 7116-10 LC User Manual
Parts & assembly sheet, Parts list

1ea W7"*E4"*H24mm
2ea 8#32-IP*1"
2ea 1/8-IP*H26mm
2ea 6ft ∅3.8
3ea P3 Orange
1ea 1/8-IP*H30mm
4ea ∅5.8*H61mm
1ea 1/8-IP*H15mm
1ea W4-1/8"*E1"*H5mm
1ea 1/8-IP*H4mm
Part Needed
Quantity
Part Needed
Quantity
Reason why
( missing, scratched, broken glass, bent, bad finish)
Comments
PARTS & ASSEMBLY SHEET
Fixture Name:
Mayfair 7116-10 LC
This fixture assembled PO:__________ Date: ________
F
IXTURE
A
SSEMBLY
I
NSTRUCTIONS
Read and review installation instruction sheet
before assembling the fixture.
7116-10 LC
Notice:
Please review the parts listing and check for all parts before assembling the fixture. If any parts
are missing or damaged, please note on this sheet and contact the place of purchase to arrange for
replacement parts.
PARTS LIST
Company Name:_______________________Co. Account #:_____________
to be filled out by retailer
Canopy
Mounting Screws
Canopy loop
ASSEMBLING THE FIXTURE (Fig 1)
The fixture frame is does not require any
assembly.
Fig 1
NOTE: I
NSTALL THE GLASS ASSEMBLY
AFTER THE FIXTURE IS HUNG.
For Customer Service, contact the place of purchase to arrange for replacement parts.
Hex Nut
Chain
Wire connectors
Nipple
Chain connector
Finial
Mounting Strap
