Assembly Instructions:

3281-BA1 BI (Moreno)

IMPORTANT:

• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Carefully remove all of the contents from the carton. See
the important notes above. Shut off the power at the circuit
breaker and completely remove the old fixture from the wall,
including the old mounting strap.

From the parts bag remove the mounting strap assembly. One
end of nipple (A) should be attached to mounting strap (B).
You may need to tighten the nut that holds this in place. Place
mounting strap (B) over the junction box so that nipple (A) is
horizontal. Secure mounting strap (B) to the junction box with
mounting screws (D) and a screwdriver. Tighten the screws
securely.

CONNECTING THE WIRES

Attach the fixture’s wires to the power supply wires from the
junction box. Connect black to black (or smooth); white to
white (or ribbed); ground to ground (green or copper). Twist the
ends of the wire pairs together, then twist on a wire connector.
Make sure all twists are in the same direction. If there is no
ground wire (green or copper) from the junction box, locate
ground screw (E) on mounting strap (B) and wrap the fixture
ground wire around the green ground screw (E). Use a
screwdriver to secure ground screw (E) onto the mounting
bracket. Tuck all wires neatly into the junction box.

FINISHING THE INSTALLATION

Place fixture backplate (C) over nipple (A) so that it protrudes
through the hole in the front of the backplate. Thread
decorative nut (G) onto nipple (A). Twist the decorative nut until
the backplate of the fixture is snug against the wall.

Slide glass shade (H) over the socket. Place rubber washer (M)
and gasket (L) over the socket and secure the glass, washer
and gasket in place by using socket tool (K) to tighten socket
ring (I) onto socket (F).

Install the provided halogen bulb. See the bulb note below.

Bulb Note: Use a tissue or paper towel to hold the bulb and
push down into the socket. Oils or dirt can cause the bulb’s
life to shorten. If dirty, rubbing alcohol is recommended for
cleaning the bulbs.

Your installation is now complete. Turn on the power and test
the fixture.

CLEANING TIPS

Treat the fixture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down
the fixture with a clean lint-free cotton or microfiber cloth. Never spray cleaner directly onto the fixture. For deep cleaning, turn off the
light and remove the glass prior to cleaning. Place the glass shades aside to clean one at a time. Hand wash glass with warm water
and mild detergent. Dry with a lint-free or microfiber cloth.

For Customer Service, contact
the place of purchase to arrange
for replacement parts.
