Fixture Name: HARLAND 3086-M1L CH
Fig. 2
For Customer Service, contact the place of purchase to arrange for replacement parts.
PARTS & ASSEMBLY SHEET
ASSEMBLING THE FIXTURE (Fig. 2)
2. Measure to determine the correct number of links
needed for proper hanging height. Use a pair of pliers
to open one link of Chain (K). Remove and discard
excess Chain (K).
3. Use one Chain Connector (L) to attach one end of
the chain toTop Loop (J) then close the chain
connector.
4. Feed the fixture wires through the chain (every three
links) and pull the wires until taut.
5. Slip Canopy Loop Collar (H) over the chain, then do
the same with Canopy (G).
6. When ready to complete the installation, use the
remaining chain connector to attach the other end of
the chain to Canopy Loop (F). Then close the chain
connector.
7. Make sure the weight of the chandelier will be
supported by the chain-not the electrical wire.
* You may now install the fixture.
Note: Complete these remaining steps after the
fixture is hung.
8. Install the light bulbs (provided) in accordance with
the fixture's specifications.
Once you complete the above steps, you may adjust
the wire into proper position
(DO NOT EXCEED MAXIMUM WATTAGE RATING)
H
L
K
G
J
M
N
Q
O
P
E
D
A
C
B
