Golden Lighting 1821-6 BI User Manual
Parts & assembly sheet, Parts list
Canopy
Wire Connectors
Top Loop
1ea @5-1/2"X1-1/2"
3ea P4 Orange
1ea 90 x 98mm
Chain
Junction Box
Screw
Spring Washer
1ea 6ft x4.2mm
2ea 8/32" x 1"
1ea @15 x 2mm
Chain Connector
Nipple
2ea @4.2X50mm
1ea @3/8 x 40mm x 5mm
1ea @3/8 x 50mm
Mounting Strap
w/ ground screw
Hex Nut
1ea 3/4"X4"
2ea @3/8 x 3mm
3ea
Part Needed
Quantity
Part Needed
Quantity
Reason why
( missing, scratched, broken glass, bent, bad finish)
Comments
Fig. 1
For Customer Service, contact the place of purchase to arrange for replacement parts.
PARTS & ASSEMBLY SHEET
1821-6 BI
Read and review installation instruction sheet before
assembling the fixture.
F
IXTURE
A
SSEMBLY
I
NSTRUCTIONS
This fixture assembled PO:__________ Date: ________
Fixture Name: Madera 1821-6 BI
Canopy Loop
with Collar
ASSEMBLING THE FIXTURE (Fig. 1)
1. Attach both ends of support chain (N) to the hooks of
Top loop (J) and hooks of fixture body (M) metal curl as
shown in the diagram.
2. Feed the fixture wires through the Top loop (J) and pull
the wires until taut.
Notice:
Please review the parts listing and check for all parts before assembling the fixture. If any parts are missing or
damaged, please note on this sheet and contact the place of purchase to arrange for replacement parts.
PARTS LIST
Company Name:_______________________Co. Account #:_____________
to be filled out by retailer
Decorative Chain
(support)
N
O
Bulb
(Not Provided)
M
