Golden Lighting 1648-M1L BUS User Manual

Parts & assembly sheet, Parts list

background image

Mounting strap

Mounting Screw

Mounting screw

1ea 4"

2ea 8/32"X28mm

2ea 8/32X1"

Wire connnector

Hex Nut

Deco nut

(round

nut)

3ea P4 Orange

2ea 8/32"X3.5mm

2ea @12mm

Canopy

Rod

Rod

1ea 130 Dia*H70mm

3ea 12.7mmDia* H12“

1ea 12.7mmDia* H6”

Part Needed

Quantity

Part Needed

Quantity

Reason why

( missing, scratched, broken glass, bent, bad finish)

Comments

For Customer Service, contact the place of purchase to arrange for replacement parts.

F

IXTURE

A

SSEMBLY

I

NSTRUCTIONS

Read and review installation instruction sheet before

assembling the fixture.

1648-M1L BUS

1. By measuring determine correct number of rods needed
for proper hanging height.
* This fixture includes 4 rods (6", 12", 12", 12")

2. To shorten the fixture; slide the excess rods off the
wires. To lengthen add additional rods.

3. Pull the fixture’s wires through the rods (H,I,J,K) until
taut and thread the rods together. Then thread to the
fixture body (L) and the swivel joint on Canopy (G).

4. Slide the glass shade (M) over Socket of fixture body
(L)and secure it by threading the Socket ring (N) on until
tight.

5. Install the light bulb in accordance with the fixture's
specification.

(DO NOT EXCEED THE MAXIMUM WATTAGE RATING)

Fig. 1

NOTE: I

NSTALL THE GLASS ASSEMBLY

AFTER THE FIXTURE IS HUNG.

PARTS & ASSEMBLY SHEET

Fixture Name: Olympia 1648-M1L BUS

This fixture assembled PO:__________ Date: ________

Notice:

Please review the parts listing and check for all parts before assembling the fixture. If any parts are missing or

damaged, please note on this sheet and contact the place of purchase to arrange for replacement parts.

PARTS LIST

Company Name:_______________________Co. Account #:_____________

below to be filled out by retailer

These three

rods may be

removed.

Bulb (Not provided)
