Page 2
AA
is a double sided crystal,
50mm
Part: PT-CRYSTAL-1323-AA
AS
is a single sided crystal,
50mm
Part: PT-CRYSTAL-1323-AS
A - crystal drop
B - crystal drop
C - crystal drop
BB
is a double sided crystal,
76mm
Part: PT-CRYSTAL-1323-BB
BS
is a single sided crystal,
76mm
Part: PT-CRYSTAL-1323-BS
CC
is a double sided crystal,
89mm
Part: PT-CRYSTAL-1323-CC
D5/D6
uses 5/6 pieces
of replacement part
PT-CRYSTAL-1323-D12
A1
A2
A4
A6
B2
BB1
CC5
D - crystal drop
A1, A2, A3, and A4
These crystal drops use
1/2/4/6 pieces of
PT-CRYSTAL-1323-D14
plus 1 piece of
PT-CRYSTAL-1323-AS
B2
uses 2 pieces of
PT-CRYSTAL-1323-D14
plus 1 piece of
PT-CRYSTAL-1323-BS
BB1
uses 1 piece of
PT-CRYSTAL-1323-D14 plus
1 piece of PT-CRYSTAL-
1323-BS
CC5
uses 5 pieces of part
PT-CRYSTAL-1323-D14 plus
1 piece of PT-CRYSTAL-
1323-CC
