Galaxy Audio DS-SP24 User Manual
Page 8
When the “1x2 WAY XOVER” is selected, the “System Setup” page will appear as follows:
To change the desired operating mode for the DS-SP24, the screen must reflect the X-Over
required and then simply pressing the “ENTER” button will bring up the following screen asking for
confirmation to load the selected operating mode:
If confirmed by pressing ENTER the selected preset mode will load. While the device is configuring
the X-Over the following screen will be appear:
The new preset mode will now be shown with an asterisk.
– Input Routing: the DS-SP24 Processor is equipped with 2 Analog Inputs (Balanced Female
XLR) and a stereo S/PDIF Digital Input (RCA connector).
The “Routing Options” page allows you to select the desired Input type:
By pressing ENTER on Input Routing and then rotating the “PM2” or “PM3” encoders, it is possible
to select the Main Inputs for the DS-SP24, allowing the User to choose between Analog or S/PDIF
Digital.
The selection can be confirmed by pressing the “ENTER” button.
The following screen shows that the Analog Input has been selected:
System Setup
Setup: 1x2 WAY XOVER
*
New Xover
[Enter] to confirm
Please Wait . . . . .
Changing Xover
Input Routing
Source: Analog
*
SYSTEM UTILITY
- Input Routing -
7
