Gain page – from this screen it is possible to set the Input Channels Level from -12dB to +6dB,
press ENTER an arrow will appear on the left of the screen “->” then use the “PM1” or “PM2”
buttons.
The value set on this screen will only affect the input level of the selected Channel A or B.
The following is an example screen for the “Gain” page that has set the Gain of Input Channel A to
+0.0dB:
Delay page – from this page it is possible to set the Input Channels Delay Time from 000.0000mS
up to 848.9984mS, by steps of 1mS or 20.8uS.
To set the Delay time press ENTER, an arrow will appear on the left of the screen “-> ” then use
the “PM2” encoder to set the Delay Time in steps of 1mS and the “PM3” for setting the “fine” Delay
Time in steps of 20.8 microseconds.
The following is an example screen for the “Delay” page where the Delay Time of Input Channel A
is set to 160.1872mS:
EQ: [x] sub-menu – from this sub-menu it is possible to set the Input Channels five available
Parametric or Shelving Filters.
The DS-SP24 allows the user to select either Bell or Shelving Parameters and assign them
independently using the 5 available filters.
In order to select the filter's type, it is necessary to have the filter's GAIN=0.0dB, then using the
“PM2” encoder, rotate it “clockwise” in order to decide the Bell filter's Bandwidth, or
“counter-clockwise” to select the Shelving filter type (Low or High) and its order (1st or 2nd).
So, in order to define the filter type for the filter number 1 (“x”=1), it is necessary from the above
Screen, to enter the filter's editing page pressing the ENTER button, and the screen has to appear
as follows:
Input-A Gain
-> Gain = + 0.0dB
Input-A Delay
-> Delay = 160.1872mS
Input-A EQ-X
1.00KHz BW1.05 0.0dB
Input-A EQ-1
-> 1.00KHz BW1.06 0.0dB
