To Edit press ENTER on the Name Page and the entering arrow will appear as in the example
below:
The first letter position will be blinking.
Select the Character position from the 6 available by rotating the “NAV/PM1” encoder, then by
using the “PM2” or “PM3” encoder it is possible to select the desired character.
Once you are happy with your name selection, press “ENTER” to confirm the edited Name. The
New name will be stored. The following example shows “Sub” replacing our previous name of
“Low”:
Source page – from this page it is possible to assign one of the following Inputs to any Output
Channel:
1. Input A
2. Input B
3. Sum of Input A and Input B
The following is an example screen for the “Source” where Input A is assigned to Output
Channel 1:
After pressing ENTER an arrow will appear on the left of the screen “->” the Input can be selected
by rotating either the “PM2” or “PM3” encoders.
Gain page – from this screen it is possible to set the Output Channels Level from -12dB to +6dB,
press ENTER an arrow will appear on the left of the screen “-> ” then use the “PM1” or “PM2”
buttons.
The value set on this screen will only affect the input level of the selected Channel 1/2/3/4.
The following is an example screen for the “Gain” page where the Gain of the Output Channel 1 is
set to +0.0dB
Out-1 Low Name
-> Name = Low
Out-1 Sub Name
Name = Sub
Out-1 Name Source
Source = InA
Out-1 Name Gain
-> Gain = + 0.0dB
