XI. MEASUREMENT
(1) Open battery cover and install a 9V battery in the battery
compartment.
(2) Turn the power on and select the desired response Time and Weighting.
If the sound source consists of short bursts or only intermittent sound
peaks, set the response to FAST. To measure an average sound level,
use the SLOW setting. Select A-weighting which filters out low
frequencies to approximate the response of the human ear at lower
SPL's. C - Weighting filters less low frequencies to approximate the
response of the human ear at higher SPL's. (a flatter response.)
(3) Select desired Level Range.
(4) Hold the instrument comfortably in your hand or mount to a tripod and
point the microphone at the suspected noise source. The sound
pressure level will be displayed.
(5) When MAX/ MIN (maximum, minimum hold) mode is chosen. The
instrument captures and holds the maximum and minimum noise
level for a long period using any of the time weightings and ranges.
Press the MAX /MIN button for 2 seconds to clear the MAX/MIN
reading. MAX/MIN ” symbol disappears.
(6) Turn OFF the instrument. Remove the battery if the meter is not to
be used for an extended period.
XII. CM-150 / CM-160Setup Test Link SE-322 USB
interface software:
Ÿ
1. 80mm Test Link CD.
2. Custom designed USB cable for Test Link.
3. 80mm USB driver CD
System Required: Ÿ
Windows 95, Windows 98, or Windows NT 4.0 and higher..
Minimum Hardware Required: Ÿ
PC or Notebook with Pentium 90MHz or higher, 32 MB RAM.
At least 5 Mb hard disk space available to install Test Link.
Recommended resolution 800X600.
Ÿ
Install TestLink:
1 It is recommended that all other applications be closed before
installing Test Link.
2. Insert setup CD disk into CD disk drive.
3. From the Start button on the Taskbar select Run.
The Test Link package contains:
