75 Operation ~ Monitoring Views
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Message Log
The Message Log displays messages indicating successful or unsuccessful site
connection and all errors. This information is displayed automatically. To open the
Message Log, click the Message Log toolbar button or select Message Log from the
Tools menu.
Gate View
The Gating button opens the Gate View window, which allows you to view gating
activity at each mic input on each unit in your site.
Select Enabled to observe unit gating information. Note that the window
shows gating activity only for units which have been added to G-Ware. The gate
indicator for each input is dark green in the gate-off condition and light green if
the input is gated on. Click Close to save the settings and exit.
Figure 5.19. Gate View window
Figure 5.16.
Message Log button
Figure 5.18.
Gating button
Figure 5.17. Message Log window
Monitoring Views
