CY62146EV30 MoBL

®

Document #: 38-05567 Rev. *C

Page 12 of 12

Document History Page

Document Title:CY62146EV30 MoBL

®

, 4-Mbit (256K x 16) Static RAM

Document Number: 38-05567

REV.

ECN NO. Issue Date

Orig. of

Change

Description of Change

**

223225

See ECN

AJU

New Data Sheet

*A

247373

See ECN

SYT

Changed Advance Information to Preliminary

Moved Product Portfolio to Page 2

Changed V

CC

stabilization time in footnote #8 from 100

µs to 200 µs

Removed Footnote #14(t

LZBE

) from Previous revision

Changed I

CCDR

from 2.0

µA to 2.5 µA

Changed typo in Data Retention Characteristics(t

R

) from 100

µs to t

RC

ns

Changed t

OHA

from 6 ns to 10 ns for both 35 ns and 45 ns Speed Bin

Changed t

HZOE

, t

HZBE

, t

HZWE

from 12 to 15 ns for 35 ns Speed Bin and 15 to

18 ns for 45 ns Speed Bin

Changed t

SCE

and t

BW

from 25 to 30 ns for 35 ns Speed Bin and 40 to 35 ns

for 45 ns Speed Bin

Changed t

HZCE

from 12 to 18 ns for 35 ns Speed Bin and 15 to 22 ns for 45

ns Speed Bin

Changed t

SD

from 15 to 18 ns for 35 ns Speed Bin and 20 to 22 ns for

45 ns Speed Bin

Changed t

DOE

from 15 to 18 ns for 35 ns Speed Bin

Changed t

DBE

from 15 to 18 ns for 35 ns Speed Bin

Changed Ordering Information to include Pb-Free Packages

*B

414807

See ECN

ZSD

Changed from Preliminary information to Final

Changed the address of Cypress Semiconductor Corporation on Page #1

from “3901 North First Street” to “198 Champion Court”

Removed 35ns Speed Bin

Removed “L” version of CY62146EV30

Changed ball E3 from DNU to NC

Removed the redundant foot note on DNU.

Changed I

CC

(Max) value from 2 mA to 2.5 mA and I

CC

(Typ) value from

1.5 mA to 2 mA at f=1 MHz

Changed I

CC

(Typ) value from 12 mA to 15 mA at f = f

max

Changed I

SB1

and I

SB2

Typ values from 0.7

µA to 1 µA and Max values from

2.5

µA to 7 µA.

Changed the AC test load capacitance from 50pF to 30pF on Page# 4

Changed I

CCDR

from 2.5

µA to 7 µA.

Added I

CCDR

typical value.

Changed t

LZOE

from 3 ns to 5 ns

Changed t

LZCE

and t

LZWE

from 6 ns to 10 ns

Changed t

LZBE

from 6 ns to 5 ns

Changed t

HZCE

from 22 ns to 18 ns

Changed t

PWE

from 30 ns to 35 ns.

Changed t

SD

from 22 ns to 25 ns.

Updated the package diagram 48-ball VFBGA from *B to *D

Updated the ordering information table and replaced the Package Name

column with Package Diagram.

*C

925501

See ECN

VKN

Added footnote #8 related to I

SB2

and

I

CCDR

Added footnote #12 related AC timing parameters
