THE WAN INTERFACE CONFIGURATION SCREEN
BRIM-WT1 USER’S GUIDE Page 15
3.2 THE WAN INTERFACE CONFIGURATION SCREEN
This section describes the features of the WAN Interface Configuration
screen. To access the WAN Interface Configuration screen from the
Features Selection screen, use the arrow keys to highlight the WAN Int.
Config. option, then press the Return key. The WAN Interface
Configuration screen shown in Figure 3-4 appears.
Figure 3-4. WAN Interface Configuration Screen
The following sections describe WAN Interface Configuration screen
fields and instructions for setting them.
Interface Number
Displays Interface Numbers 02-26. Use this field to configure the
Interface Numbers you assigned to the Timeslots at the WAN Physical
Configuration screen. This field only displays the active SYNC and T1
interfaces.
Data Compression
Displays the status of Data Compression. Select Yes to activate Data
Compression or No to de-activate. Data Compression is not supported at
this time.
