BRIM-WT1 USER’S GUIDE Page 9
CHAPTER 3
LOCAL MANAGEMENT
This Chapter explains how to use the BRIM-WT1 local management
screens. The
WAN Physical Configuration screen and the WAN
Interface Configuration screen appear as local management menu
selections after you successfully install the BRIM-WT1 into the
MicroMMAC. Refer to the MicroMMAC User’s Guide for instructions
on how to setup and access local management.
3.1 The WAN PHYSICAL CONFIGURATION SCREEN
To access the WAN Physical Configuration screen from the Feature
Selection screen, use the arrow keys to highlight the WAN Physical
Configuration option, then press the
Return key. The WAN Physical
Configuration screen shown in Figure 3-1 appears.
Figure 3-1. WAN Physical Configuration Screen
SAVE WAN INT CONFIG RETURN
-F6-
MicroMMAC/WT1 LOCAL MANAGEMENT
Cabletron MMW Revision xx.xx.xx
WAN PHYSICAL CONFIGURATION
00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00
01-08
09-16
17-24
T1 Timeslot Configuration
Active WAN Port: T1
Default WAN Port: T1
SYNC Port Type: V.35
Force CTS True: Yes
Force DSR True: No
T1 Timeslot View: Active
T1 Line Coding: B8ZS
T1 Frame Type: ESF
T1 Xmit Clk Src: LOCAL TIMING
T1 Line Buildout: 0 db
