CHAPTER 3: LOCAL MANAGEMENT
Page 14 BRIM-WT1 USER’S GUIDE
3. The T1 Timeslot View field displays New and the cursor
automatically moves into the Timeslot Configuration table.
4. Use the arrow keys to move to the desired Timeslots in the Timeslot
Configuration table.
5. Type the desired Interface Number (03 to 26; or zero (00) for unused
Timeslots).
Note: The MicroMMAC automatically assigns Interface 01 for Ethernet,
and Interface 02 for the SYNC port.
6. Press the Return key.
7. Repeat steps 4 -6 to complete the configuration.
8. Use the arrow keys to highlight the SAVE command.
9. Press the Return key or press F6. The message “Save Done!” appears
and the changes are saved to memory.
10. Use the arrow keys to highlight the T1 Timeslot View field.
11. Press the Return key until the Active selection appears. Verify that the
desired changes have taken effect. The T1 configuration is complete.
