FAD - 4 DIGITAL LOADCELL JUNCTION BOX 02.05.00 FAD4_2RM 2 12 of 20
Master transmission: (PAR 3)
STX ADD p 3 BCS2 BCS1 ETX
Slave response:
STX ADD p 3 a b c d e f BCS2 BCS1 ETX
a = Decimal digits (0, 1, 2, 3, 4) d = Dual digital filter 0=No 1=Yes
b = Autozero maintenance 0=No 1=Yes e = Leading zero blank 0=No 1=Yes
c = Autozero on power up 0=No 1=Yes f = Reserved
Q :
DOWNLOAD SETPOINT
Used to download the two digital setpoint values.
Master transmission:
STX ADD Q x yyyyy BCS2 BCS1 ETX
x : One digit (1-2) defining setpoint number.
yyyyy : 5 digits defining setpoint value(ASCII decimal MSD). No decimal point.
Slave response:
STX ADD ACK or NAK BCS2 BCS1 ETX
A NAK is returned if the values are not within Max.
q :
UPLOAD SETPOINTS
Used to upload setpoint values in the DJB memory.
Master transmission:
STX ADD q x BCS2 BCS1 ETX
Slave response:
STX ADD q x yyyyy BCS2 BCS1 ETX
x : One digit (1-2) defining setpoint number.
yyyyy : 5 digits defining setpoint value(ASCII decimal MSD).
R :
RESET SLAVE
Resets the slave to its power on condition.
Master transmission:
STX ADD R BCS2 BCS1 ETX
Slave response: NONE.
S:
DOWN LOAD SETUP
Setup 1 is used to download the tilt switch interface parameters while setup 2 is used to download
serial port 1 (RS485) interface parameters.
Master transmission: (SETUP 1)
STX ADD S 1 X Y RRR BCS2 BCS1 ETX
where X=0 for normally open contact (N.O) or X=1 for normally closed contact (N.C)
Y= 0-9 sec the ON/OFF delay for contact debounce.
RRR= Reserved. If both X=0 and Y=0 the tilt function is disabled.
Slave response:
STX ADD ACK or NAK BCS2 BCS1 ETX
A NAK is returned if the values are out of range.
