CHAIN SAW

USER'S MANUAL

ATTENTION! Spinning the engine for too long

with the choke lever pulled out will result in ﬂ ooding
of the engine and problems with starting it up.

5. Prior to starting work, leave the engine to warm

up for a few minutes to get up to operating
temperature.

Starting a warm engine

1. Set the main power switch to the top position

(see Fig. 7, point 1)

2. Pull on the handle of the starting cord until the

engine starts up (Fig. 8)
DO NOT USE THE CHOKE!

ATTENTION! In the event that the fuel in the fuel

tank was completely used up, after pouring in fuel,
repeat the steps for STARTING A COLD ENGINE.

Speed control

To increase speed, ﬁ rst use the palm of your hand

to push down the throttle safety switch
(Fig. 7, point 4) and then use your ﬁ nger to
pull on the throttle trigger (Fig. 7, point 5)

To lower the speed, release the throttle trigger

Stopping the engine

Release the throttle trigger (Fig. 7, point 5) and switch the main power switch to the "Stop" position

(Fig. 1, point 1).

WARNING
The engine exhaust fumes contain chemical substances that are damaging to health. Never inhale these
fumes. Always start the chain saw outdoors.

Checking chain lubrication

ATTENTION! Adhere to safety provisions and
prevent the guide bar from coming into contact
with the surface of the terrain. Use this power tool
safely and maintain a minimum distance of 20 cm
from the ground.

Before starting work, check the chain lubrication
and the amount of oil in the oil tank. Start the
chain saw and hold it above the ground. If you see

Fig. 7

Fig. 8

Fig. 9

Turning the chain saw on and off
