Machine description and included contents
Description of the power tool (see Fig. 1)
1. Throttle safety switch
2. Throttle
trigger
3. Main power switch
4. Fuel tank cap
5. Oil tank cap
6. Front
handle
7. Chain
8. Guide
bar
9. Safety
brake
10. Starting handle
11. Air fi lter cover screw
12. Choke lever
13. Throttle trigger lock
Included contents: Petrol chain saw, 405 mm guide bar, Oregon chain, plastic guide bar cover, calibrated fuel
mixing container, spare spark plug, tool set with fi le.
4. MACHINE DESCRIPTION AND INCLUDED
CONTENTS
Fig. 1
1
12
11
10
9
8
7
6
5
4
3
2
13
