28 VB475
English
Options
To connect any auxiliary device to the player, refer to the manual supplied by the
manufacturer of the auxiliary unit.
Accessories and hardware
The following components come with the player:
Qty Item Picture Qty Item Picture
1 Mounting
bracket 1 Storage box for
front panel
1 Nut M5 1 Power
connector
1 Assembly bar 1 Remote control
1 Screw (B15
x 16) 1 Trim ring
1 Bolt 1 Battery
2 Keys
Installing the player
If the vehicle has a two-inch high slot in the dashboard for a DVD player, you may
directly install the player in the dashboard.
1. To avoid shorts in the electrical system, disconnect the vehicle’s battery.
2. Connect the mounting bolt on the back of the player using a crescent wrench.
3. Check all the electrical connections based on the wiring diagram.
4. Insert the power connector into the player’s power receptacle on the back of the
player.
