Configuring the GbE Interconnect Switch Using the Web-Based Management Interface
Compaq ProLiant BL p-Class GbE Interconnect Switch User Guide 4-25
COMPAQ CONFIDENTIAL Codename: Vanilla Part Number: 263680-001 Last Saved On: 4/23/02 10:02 AM
Configuring the Restart Egress Bandwidth Settings
When you select Restart Egress Bandwidth from the Port Bandwidth menu, the following
screen is displayed.
To configure egress bandwidth for a specific port:
1. Select the desired port in the Port Num field.
2. Type a number between 1 and 127 in the Egress Bandwidth (1–127 Units) field.
3. Click Apply to save the change or addition.
4. Select Restart System from the Maintenance menu.
5. Select Yes to save the settings.
6. Click Restart. The system reboots and saves your settings.
NOTE: To delete an entry, click the icon in the Delete column on the Egress Bandwidth
Setup Table.
Displaying the Current Egress Bandwidth Table
When you select Current Egress Bandwidth from the Port Bandwidth menu, the following
screen is displayed.
Current Egress Bandwidth Table is a read-only screen displaying current egress bandwidth
information.
