6 - Appendix
Technical Specifications
E-MU 1616/1616M CardBus Digital Audio System 91
MIC PREAMP/LINE INPUT
HI-Z LINE INPUT
Gain Range: -15 dB to +51 dB
Max Level: 19.5 dbV
THD+N: -101 dB (.0009%), -1 dBFS, 20kHz BW
SNR: 110 dB, (A-weighted, 20kHz BW)
Dynamic Range: 110 dB, (A-weighted, 20kHz BW)
Crosstalk: Minimum Gain: -140 dB (1kHz)
Maximum Gain: -80 dB (1kHz)
Frequency Response: +0.0/-0.06 dB, 20 Hz - 20 kHz
Input Impedance: 1M ohm
CMRR: -75 dB (60Hz)
MICROPHONE PREAMP
Gain Range: -2 dB to +64 dB
Max Level: -6.5 dbV
THD+N: Min Gain: -102 dB (.0008%), (1kHz, -1 dBFS, 20kHz BW)
40dB Gain: -91dB (.0029%)
60dB Gain: -69 dB (.035%)
SNR: 110 dB (A-weighted, min. gain)
Frequency Response: 20 Hz - 20 kHz ±0.08 dB (20Hz - 20kHz, gain +40dB)
Input Impedance: 1.5 Kohm
CMRR: -67 dB (60Hz, 35 dB gain, -1 dBFS)
Crosstalk: -100 dB (1 kHz, 40 dB gain, -1 dBFS)
HEADPHONE AMP
Frequency Response: +0.0/-0.07 dB, 20 Hz - 20 kHz
THD+N: (1 kHz, max. level) 24 ohm load: -80 dB (0.01%)
600 ohm load: -94 dB (0.002%)
SNR: 112 dB (A-weighted, 20kHz BW)
Dynamic Range: 112 dB (A-weighted, 20kHz BW)
Stereo Crosstalk: 24 ohm load: < -43 dB (1kHz at 0 dBFS)
600 ohm load: < -90 dB (1kHz at 0 dBFS)
Max Output Power: 100 mW (24 Ω load)
Output Impedance: 22 ohms
Gain Range: 85 dB
Specifications: 1616 System
