6 - Appendix
Technical Specifications
E-MU 1616/1616M CardBus Digital Audio System 87
Technical Specifications
Specifications: 1616 m System
GENERAL
Sample Rates 44.1 kHz. 48 kHz, 96 kHz, 192 kHz from internal crystal
Accepts externally supplied clock from S/PDIF or ADAT
Bit Depth 16 or 24-bits
Hardware DSP 100MIPs custom audio DSP.
Zero-latency direct hardware monitoring with effects
Converters & OpAmps ADC - AK5394 (AKM)
DAC - CS4398 (Cirrus Logic)
OpAmp - NJM2068M, NJM2122, NJM2082 (JRC)
WDM Drivers 2-in/8-out at 44.1kHz, 48kHz, 88.2kHz, 96kHz
2-in/4-out at 176.4kHz & 192kHz
MicroDock m Power Use .32A @ +48VDC 15.4 Watts
ANALOG LINE INPUTS
Type Servo-balanced, DC-coupled, low-noise input circuitry
Level (software selectable) Professional: 18 dBV maximum (balanced)
Consumer: 6 dBV maximum (unbalanced)
Frequency Response 20 Hz - 20 kHz, +0.0/-0.03 db
THD + N -110 dB (.0003%) (-1 dBFS, 20kHz BW)
SNR 120 dB (A-weighted, 20kHz BW)
Dynamic Range 120 dB (A-weighted, 20kHz BW)
Channel Crosstalk -120 dB, (1 kHz)
Common-mode Rejection -79 dB at 60Hz
Input Impedance 10K ohm
ANALOG LINE OUTPUTS
Type Balanced, low-noise, 2-pole low-pass differential filter,
AC-coupled
Level (software selectable) Professional: 18 dBV maximum (balanced)
Consumer: 6 dBV maximum (unbalanced)
Frequency Response 20 Hz - 20 kHz, +0.0/-0.03 dB
THD + N -105 dB (.0005%) (-1dBFS, 20kHz BW)
SNR 120 dB (A-weighted, 20kHz BW)
Dynamic Range 120 dB (A-weighted, 20kHz BW)
Stereo Crosstalk < -115 dB, 1kHz
Output Impedance 560 ohms
