6 - Appendix
Technical Specifications
90 Creative Professional
Specifications: 1616 System
GENERAL
Sample Rates 44.1 kHz. 48 kHz, 88.2kHz, 96 kHz, 176.4kHz & 192 kHz
from internal crystal.
Accepts externally supplied clock from S/PDIF or ADAT
Bit Depth 16 or 24-bits
Hardware DSP 100MIPs custom audio DSP.
Zero-latency direct hardware monitoring with effects
Converters & OpAmps ADC - PCM1804 (TI)
DAC - CS4392 (Cirrus Logic)
OpAmp - NJM2068M, NJM2122, NJM2082 (JRC)
WDM Drivers 2-in/8-out at 44.1kHz, 48kHz, 88.2kHz, 96kHz
2-in/4-out at 176.4kHz & 192kHz
MicroDock Power Use .20A @ +48VDC 10 Watts
ANALOG LINE INPUTS
Type Servo-balanced, DC-coupled, low-noise input circuitry
Level (software selectable) Professional: 18 dBV maximum (balanced)
Consumer: 6 dBV maximum (unbalanced)
Frequency Response 20 Hz - 20 kHz, +0.05/-0.05 db
THD + N -102 dB (.0007%) -1 dBFS, 20kHz BW
SNR 110 dB (A-weighted, 20kHz BW)
Dynamic Range 110 dB (A-weighted, 20kHz SPCL)
Channel Crosstalk < -120 dB, (1 kHz)
Common-mode Rejection -50 dB at 60Hz
Input Impedance 10K ohm
ANALOG LINE OUTPUTS
Type Balanced, low-noise, 2-pole low-pass differential filter,
AC-coupled
Level (software selectable) Professional: 18 dBV maximum (balanced)
Consumer: 6 dBV maximum (unbalanced)
Frequency Response 20 Hz - 20 kHz, +0.0/-0.08 dB
THD + N -98 dB (.0012%) (-1dBFS, 20kHz BW)
SNR 112 dB (A-weighted, 20kHz BW SPCL)
Dynamic Range 112 dB (A-weighted, 20kHz SPCL)
Stereo Crosstalk < -115 dB, 1kHz
Output Impedance 560 ohms
