6 - Appendix
Technical Specifications
E-MU 1616/1616M CardBus Digital Audio System 89
CARD HEADPHONE AMP
Frequency Response: +0.05/-0.0 dB, 20 Hz - 20 kHz
THD+N: 24 ohm load: -80 dB (0.01%)
65 ohm load: -85 dB (0.0056%)
600 ohm load: -96 dB (0.0016%)
SNR: 116 dB (A-weighted, 22kHz BW)
Dynamic Range: 116 dB (A-weighted, 22kHz BW)
Stereo Crosstalk: -99 dB (1kHz at -1 dBFS, 660 ohm load)
Max Output Power: 50 mW (24 Ω load)
Output Impedance: 22 ohms
TURNTABLE INPUT RIAA equalized phono input
Frequency Response: +/-0.5 dB, 50 Hz - 20 kHz
Deviation from RIAA +0.2/-0.3 dB (50Hz to 15kHz)
THD+N: -92 dB (.0025%) (20kHz BW, unbalanced)
SNR: 107 dB (A-wt, 20kHz BW)
Stereo Crosstalk: < -80 dB (1kHz at -1 dBFS)
Maximum Level: Professional: 60 mV RMS
Consumer: 15 mV RMS
Input Capacitance: 220 pF
Input Impedance: 47K ohm
DIGITAL I/O
S/PDIF • 2 in/2 out coaxial (transformer coupled)
• 2 in/2 out optical (software switchable with ADAT)
• AES/EBU or S/PDIF (switchable under software control)
ADAT • 8 channels, 24-bit @ 44.1/48 kHz
• 4 channels, 24-bit @ 96 kHz
• 2 channels, 24-bit @ 192 kHz
MIDI 2 MIDI in, 2 MIDI out
SYNCHRONIZATION
Internal Crystal Sync: 44.1kHz, 48 kHz, 88.2kHz, 96 kHz, 176.4kHz, 192 kHz
ADAT, S/PDIF (optical or coaxial)
RMS JITTER @ 44.1K
(Measured via Audio Precision 2) SRSync SourceRMS jitter in picoseconds
44.1 kHz internal Crystal 596ps
44.1 kHz Optical Input 795ps
Specifications: 1616 m System
