E-MU 1616M PCIe User Manual
Page 82
6 - Appendix
Using High Sample Rates
82
Creative Professional
E-MU 1616 Hardware Inputs & Outputs at 176.4k or 192k
Source
Input
Analog &
SPDIF
Output
Analog &
SPDIF
Input
SPDIF &
ADAT
Output
SPDIF &
ADAT
Input
Analog &
ADAT
Output
Analog &
ADAT
ADAT
0
0
2
2
2
2
Microphone
2
- - - - - - - -
2
- - - - - - - -
2
- - - - - - - -
Line 1
2
2
2
2
2
2
Line 2
2
2
0
2
2
2
Line 3
(output)
- - - - - - - -
2
- - - - - - - -
2
- - - - - - - -
2
S/PDIF
2
2
2
2
0
0
Total
8
8
8
8
8
8
At the 192kHz sample rate, you may choose one of these three options:
1. Keep all Analog I/O, but lose S/PDIF
3. Keep S/PDIF & ADAT, but lose
2. Keep all Analog I/O, but lose ADAT
Line Inputs 2L/2R & Line Outputs 3L/3R
