OPERATING INSTRUCTIONS
SPEAKER CONNECTION
Connect each speaker to the corresponding speaker terminals on the back panel
of the main unit. Make sure that the left speaker plug is connected to the left (L)
speaker jack and the right speaker plug is connected to the right (R) speaker jack.
COOLING FAN
A cooling fan is employed on the back panel of this player and will operate when
the unit is powered up. Do not obstruct the ventilation of this fan and ensure a clear
space of approximately 2 inches exists between the back panel and any enclosure.
R
L
SPEAKER
ES8_ib.p65
8/10/01, AM 11:00
