Statistics
5-2 Viewing the Ring Station List
from the command line (stand-alone mode):
1. From the appropriate directory, type:
spmarun e5stats
The Ring/Stn Statistics window, Figure 5-1 , will appear.
Figure 5-1. The Ring/Stn Statistics Window
This window lists the interfaces with their corresponding numbers that are
available on your Token Ring device. Use the scroll bar on the side of the display
window if necessary to see the full list of Ring Names. This window allows you to
choose a ring and then display the Ring and Station Statistics window specific to
that ring. You may also quit the Token Ring statistics tool from this window by
clicking mouse button 1 on
.
Viewing the Ring Station List
From the Ring/Stn Statistics window, select the network from which you would
like to gather statistics and click mouse button 1 on
. The Ring and
Station Statistics window, Figure 5-2 , will appear.
NOTES
The spmarun script invoked first in the above command temporarily sets the environment
variables SPMA needs to operate; be sure to use this command any time you launch an
application from the command line. This script is automatically invoked when you launch
an application from the icon menu or from within the Hub View.
A community name with Read access will be sufficient to view the statistics.
If there is a hostname mapped to your TRMMIM’s IP address, you can use
in place of to launch this application. Please note, however, that the
hostname is not the same as the device name which can be assigned via Local
Management and/or SPMA; you cannot use the device name in place of the IP address.
