Ring Map
3-12 Viewing Station-specific Information
Table 3-1. Error Status Codes and Definitions
Active Monitor
This field allows you to determine whether or not the management station will
participate in active monitor contention. The contention process occurs as part of
the recovery procedures initiated after certain ring error situations, and is used to
select a new Active Monitor for the ring. If you disallow contention for the
selected management station, that station will not participate in the contention
process, and will therefore never be chosen as Active Monitor.
Code Error
0 No problem detected
32
Ring Recovery Error
The management station has observed claim token MAC frames on the ring.
64
Single Station
The management station has sensed it is the only station on the ring.
128
Counter Overflow
One of the management station’s error counters has incremented from 254 to 255.
256
Remove Received
The management station has received a remove ring station MAC frame request
and has removed itself from the ring.
1024
Auto-Removal Error
The management station has failed the lobe wrap test resulting from the beacon
auto-removal process and has removed itself from the ring.
2048
Lobe Wire Fault
The management station has detected an open or short circuit in the cable between
itself and the wiring concentrator or hub.
4096
Transmit Beacon
The management station is transmitting beacon frames to the ring.
8192
Soft Error
The management station has transmitted a report error MAC frame.
16384
Hard Error
The management station is presently transmitting beacon frames to or receiving
beacon frames from the ring.
32768
Signal Loss
The management station has detected a loss of signal on the ring.
131072 No Status, Open Not Completed
