5
● To avoid permanent damage to the electronic ignition system,
NEVER rotate the propeller on your DLE engine with the electronic
ignition system switched on and the plugs not installed in the
plug caps.
● If you elect to not use a smoke system with your engine and
aircraft, the two included brass fi ttings must be installed in the
muffl er and then obstructed to prevent exhaust from leaking
into the cowling. To do this use two short segments of neoprene
fuel line and two (GPMQ4166) fuel-line plugs (not included).
Installation Instructions
Prepare the Engine for Installation
Before beginning installation, it’s a good idea to plan the location
of the various components of the engine. Many of the following
steps may need to be completed in a different order than listed.
1. Check to see that all screws and bolts are tight. Check carefully for
any cracks, broken or missing parts. Tighten or replace any damaged
or missing parts before proceeding.
2. Install the silicone wire cover over the pick up lead coming from
the engine (cut the excess silicon wire covers) and connect the lead
to the pick–up lead from the Electronic Ignition Module. Secure
the connection with the included three pin connector securing clip.
