PmodRF1 Reference Manual

www.digilentinc.com

page 2 of 2

Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.



Connector J1 – SPI Communications
Pin

Signal

Description

1

SEL

Slave Select

2

MOSI

Master out/Slave in Data

3

MISO

Master in/Slave out Data

4

SCLK

Serial Clock

5

GND

Power Supply Ground

6

VCC

Power Supply (3.3V)

7

IRQ

Interrupt Request Signal

8

RST

Hardware Reset (Active Low)

9

SLP_TR

Multipurpose Control Signal

10

CLKM

Clock Output

11

GND

Power Supply Ground

12

VCC

Power Supply (3.3V)
