Digilent PmodREG1 User Manual
Page 2
Document Title
Digilent Confidential
Digilent, Inc.
www.digilentinc.com Copyright Digilent, Inc.
Page
2
the regulator output from J1, remove the
shorting block on JP1.
The 2-pin header, J4, can be used to take
power from the PmodREG1 module to power
another device via a two-wire MTE cable.
Many Digilent embedded control boards and
Pmod module boards are equipped with a two-
pin connector as an optional way to provide
power to the board.
