Memory Pin
Assignments
ADDR Pin FPGA
Pin
DATA
Pin
FPGA
Pin
ADR23 C3 DB15 D2
ADR22 A3 DB14 E2
ADR21 M4 DB13 D1
ADR20 D3 DB12 E1
ADR19 G5 DB11 F2
ADR18 H3 DB10 G2
ADR17 G4 DB9 G1
ADR16 L4 DB8 H1
ADR15 F3 DB7 R3
ADR14 M3 DB6 R1
ADR13 L5 DB5 P1
ADR12 N3 DB4 P2
ADR11 F5 DB3 N1
ADR10 F4 DB2 N2
ADR9 E3 DB1 M1
ADR8 G3 DB0 M2
ADR7 K4
ADR6 H4
ADR5 K3
ADR4 J4
ADR3 L3
ADR2 K5
ADR1 J3
Hirose FX2 Connector Pin Assignments
J1A Name FPGA J1B Name FPGA
1 VCC3V3 1 SHIELD
2 VCC3V3 2 GND
3 TMS C13 3 TDO-ROM
4 JTSEL 4 TDK C14
5 TDO-FX2 5 GND
6 FX2-IO1 B4 6 GND
7 FX2-IO2 A4 7 GND
8 FX2-IO3 C5 8 GND
9 FX2-IO4 B5 9 GND
10 FX2-IO5 E6 10 GND
11 FX2-IO6 D6 11 GND
12 FX2-IO7 C6 12 GND
13 FX2-IO8 B6 13 GND
14 FX2-IO9 E7 14 GND
15 FX2-IO10 D7 15 GND
16 FX2-IO11 C7 16 GND
17 FX2-IO12 B7 17 GND
18 FX2-IO13 D8 18 GND
19 FX2-IO14 C8 19 GND
20 FX2-IO15 A10 20 GND
21 FX2-IO16 B10 21 GND
22 FX2-IO17 D10 22 GND
23 FX2-IO18 E10 23 GND
24 FX2-IO19 B11 24 GND
25 FX2-IO20 C11 25 GND
26 FX2-IO21 D11 26 GND
27 FX2-IO22 E11 27 GND
28 FX2-IO23 B12 28 GND
29 FX2-IO24 C12 29 GND
30 FX2-IO25 A13 30 GND
31 FX2-IO26 B13 31 GND
32 FX2-IO27 A14 32 GND
33 FX2-IO28 B14 33 GND
34 FX2-IO29 B16 34 GND
35 FX2-IO30 C16 35 GND
36 FX2-IO31 C15 36 GND
37 FX2-IO32 D14 37 GND
38 FX2-IO33 D15 38 GND
39 FX2-IO34 D16 39 GND
40 FX2-IO35 E15 40 GND
41 FX2-IO36 E16 41 GND
42 FX2-IO37 F14 42 GND
43 FX2-IO38 F15 43 GND
44 FX2-IO39 H15 44 GND
45 FX2-IO40 H16 45 GND
46 GND 46 FX2-CLKIN C9
47 FX2-CLKOUT D9 47 GND
48 GND 48 FX2-CLKIO B8
49 VCCFX2 49 VCCFX2
50 VCCFX2 50 SHIELD
