D2-FT Reference Manual Digilent, Inc.
www.digilentinc.com © Digilent, Inc. Page 6
Table 2. D2-FT Expansion Connector Pinout
A1 A2 B1 B2 C1 C2
Pin #
Signal
FPGA
Pin
Signal
FPGA
Pin
Signal
FPGA
Pin
Signal
FPGA
Pin
Signal
FPGA
Pin
Signal
FPGA
Pin
1 GND GND GND GND GND GND
2 VU VU VU VU VU VU
3 VCC33 VCC33 VCC33 VCC33 VCC33 VCC33
4 ADR0 J14 PAI01 B12 ADR0 J14 PBI01 M10 PCADR0 N3 PCI01 F2
5 DB0 K16 PAI02 C12 DB0 K16 PBI02 R11 PCDB0 P2 PCI02 E1
6 ADR1 K13 PAI03 A13 ADR1 K13 PBI03 P10 PCADR1 L5 PCI03 F4
7 DB1 K15 PAI04 D12 DB1 K15 PBI04 T10 PCDB1 N1 PCI04 E2
8 ADR2 K14 PAI05 B13 ADR2 K14 PBI05 N10 PCADR2 M3 PCI05 E3
9 DB2 L16 PAI06 A14 DB2 L16 PBI06 P9 PCDB2 N2 PCI06 D1
10 ADR3 K12 PAI07 E11 ADR3 K12 PBI07 R10 PCADR3 L4 PCI07 F5
11 DB3 L15 PAIO8 C16 DB3 L15 PBI08 N9 PCDB3 M1 PCI08 D2
12 ADR4 L14 PAI09 E13 ADR4 L14 PBI09 N8 PCADR4 L3 PCI09 D3
13 DB4 M16 PAI010 D14 DB4 M16 PBI010 R9 PCDB4 M2 PCI010 C1
14 ADR5 L13 PAI011 D16 ADR5 L13 PBI011 P8 PCADR5 K5 PCI011 E4
15 DB5 M15 PAI012 F12 DB5 M15 PBI012 R8 PCDB5 L1 PCI012 A3
16 WE M14 PAI013 D15 WE M14 PBI013 N7 PCWE K3 PCI013 C2
17 DB6 N16 PAI014 E14 DB6 N16 PBI014 T7 PCDB6 L2 PCI014 B3
18 OE L12 PAI015 E16 OE L12 PBI015 P7 PCOE K4 PCI015 C4
19 DB7 N15 PAI016 F13 DB7 N15 PBI016 R7 PCDB7 K1 PCI016 A4
20 CSA D8 PAI017 E15 CSB N14 PBI017 M7 PCCS J3 PCI017 DS
21 LSBCLK P16 PAI018 F14 LSBCLK P16 PBI018 T6 PCCLK K2 PCI018 B4
22 MA1DB0 D9 MA2DB0 F16 MB1DB0 M13 MB2DB0 P6 MC1DB0 J4 MC2DB0 C5
23 MA1DB1 A9 MA2DB1 G12 MB1DB1 T14 MB2DB1 R6 MC1DB1 J1 MC2DB1 A5
24 MA1DB2 C9 MA2DB2 F15 MB1DB2 N12 MB2DB2 N6 MC1DB2 J2 MC2DB2 E6
25 MA1DB3 B9 MA2DB3 G14 MB1DB3 R14 MB2DB3 T5 MC1DB3 H4 MC2DB3 B5
26 MA1DB4 D10 MA2DB4 G16 MB1DB4 P13 MB2DB4 P5 MC1DB4 H1 MC2DB4 C6
27 MA1DB5 A10 MA2DB5 G13 MB1DB5 T13 MB2DB5 R5 MC1DB5 H3 MC2DB5 A6
28 MA1DB6 C10 MA2DB6 G15 MB1DB6 M11 MB2DB6 M6 MC1DB6 H2 MC2DB6 D6
29 MA1DB7 B10 MA2DB7 H14 MB1DB7 R13 MB2DB7 T4 MC1DB7 G4 MC2DB7 B6
30 MA1ASTB E10 MA2ASTB H16 MB1AST P12 MB2AST P4 MC1ASTB G1 MC2ASTB C7
31 MA1DSTB A11 MA2DSTB H13 MB1DST T12 MB2DST R4 MC1DSTB G3 MC2DSTB A7
32 MA1WRT C11 MA2WRT H15 MB1WRT N11 MB2WRT N5 MC1WRT G2 MC2WRT D7
33 MA1WAIT B11 MA2WAIT J16 MB1WAIT R12 MB2WAIT T3 MC1WAIT G5 MC2WAIT E7
34 MA1RST D11 MA2RST J13 MB1RST P11 MB2RST M4 MC1RST F1 MC2RST B7
35 MA1INT A12 MA2INT J15 MB1INT T11 MB2INT P1 MC1INT F3 MC2INT A8
36 JTSELA JTSELB JTSELC
37 TMS TMS TMS
38 TCK TCK TCK
39 TDOA CLK0 T9 TDOB TDOC CLK1 T8
40 TDIA GND TDIB TDIC GND
