chipKIT Pmod Shield-Uno Reference Manual
www.digilentinc.com
page 4 of 7
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
Appendix: chipKIT Pmod Shield-Uno Pinout Tables
J1 Pins
Uno32
Pin #
PIC32
Pin #
Pin
Signal
Notes
8
44
J1-01
IC3/PMCS2/PMA15/INT3/RD10
34
53
J1-02
PMRD/CN14/RD5
9
51
J1-03
OC4/RD3
35
45
J1-04
IC4/PMCS1/PMA14/INT4/RD11
10
8
J1-05
SS2/PMA2/CN11/RG9
selected by JP4
10
52
J1-05
PMWR/OC5/IC5/CN13/RD4
selected by JP4
36
54
J1-06
CN15/RD6
11
6
J1-07 or
J1-09
SDO2/PMA3/CN10/RG8
selected by JP5/JP7
37
55
J1-08
CN16/RD7
12
5
J1-09 or
J1-07
SDI2/PMA5/CN8/RG7
selected by JP7/JP5
38
35
J1-10
U1RTS/BCLK1/SCK1/INT0/RF6
13
4
J1-11
SCK2/PMA5/CN8/RG6
39
31
J1-12
PMA9/U2RX/SDA2/CN17/RF4
40
32
J1-14
PMA8/U2TX/SCL2/CN18/RF5
42
16
J1-15
PGED1/PMA6/AN0/VREF+/CVREF+/CN2/RB0
41
15
J1-16
PGC1/AN1/VREF-/CVREF-/CN3/RB1
J3 Pins
Uno32
Pin #
PIC32
Pin #
Pin
Signal
Notes
0
34
J3-01
U1RX/SDI1/RF2
26
60
J3-02
PMD0/RE0
1
33
J3-03
U1TX/SDO1/RF3
27
61
J3-04
PMD1/RE1
2
42
J3-05
IC1/RTCC/INT1/RD8
selected by JP4
28
62
J3-06
PMD2/RE2
selected by JP4
3
46
J3-07
OC1/RD0
29
63
J3-08
PMD3/RE3
selected by JP5/JP7
4
59
J3-09
RF1
30
64
J3-10
PMD4/RE4
selected by JP7/JP5
5
49
J3-11
OC2/RD1
31
1
J3-12
PMD5/RE5
6
50
J3-13
OC3/RD2
32
2
J3-14
PMD6/RE6
7
43
J3-15
IC2/U1CTS/INT2/RD9
33
3
J3-16
PMD7/RE7
