Design Implementation

•

A bunch of things happen under the hood!!

–

An HDL representation of the design will be created in the hdl directory

–

Each submodule is synthesized into netlists stored in subdirectories under

implementation

–

Ngdbuild combines the netlists and performs DRCs

–

The netlist is placed and routed (par) and a bitfile is generated

–

The software device drivers are compiled into libraries

–

The user application is compiled and linked against the libraries to created

an executable elf file

–

Finally, the BRAMs in the bit file which comprise the program memory are

configured with the contents of the elf file

–

Implementation/download.bit is the file to program the FPGA!
