Cub Cadet 2186 - Manual (Page 41)

-41-
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 603-0857 Idler Assembly 1
2 603-0183A Plate Assy, Mounting 1
3 603-0203 Handle, Tension 2
4 603-0729
777S30014
777S30018
777S30503 Deck Housing Assembly
Graphic, Warning
Graphic, Deck Safety
Graphic, Deck Safety
1
1
1
1
5 631-0094A Chute Assembly, Discharge 1
6 703-1890 Wheel, Deck w/Fitting 2
7 703-2559 Bracket, Stop 1
8 703-3359 Baffle, Skirt 2
9 703-3742 Belt Cover, LH 1
10 703-3743 Belt Cover, RH 1
11 710-0260A Bolt, Carriage, 5/16-18 x .62 6
12 710-0751 Screw, Hex Cap, 1/4-20 x .62 2
13 710-1010 Screw, Hex Cap, 1/2-20 x 3.0 1
14 710-1611B Screw, Self Tap, 5/16-18 x .75 6
15 710-3008 Screw, Hex Cap, 5/16-18 x .75 1
16 710-3178 Bolt, Carriage, 3/8-16 x .75 GR5 4
17 711-3314 Pin, Roller, 1/2 Dia x 7.31 1
18 712-0239 Nut, Hex Lock, 1/2-20 1
19 712-0431 Nut, Flange Lock, 3/8-16 11
20 712-3004A Nut, Flange Lock, 5/16-18 7
21 712-3006 Nut, Hex, 1/4-20 GR5 2
22 712-3010 Nut, Hex, 5/16-18, GR5 6
23 714-0115 Pin, Cotter, 1/8 Dia x 1 1
24 715-3003 Pin, Spiral Spring, 3/16 Dia x .75 2
25 726-3045 Button Plug 2
26 731-3005 Front Roller 1
27 731-3316 Plug, Mulch 1
28 732-3127 Spring, Comp, .66 OD x 1.8 2
29 732-0861 Spring, Ext, .162 Dia x 1.25 OD 1
30 734-0973 Wheel, Deck, 5.0 x 1.38 2
31 736-0105 Washer, Bell. .401 x .870 x .063 2
32 736-0119 Washer, Lock, 5/16 6
33 736-0179 Washer, Flat, 1/2 x 1.25 x .10 1
34 736-0270 Washer, Bell, .265 x .75 x .062 2
35 736-0272 Washer, Flat, .510 x 1 x .060 4
36 738-0143 Bolt, Shoulder, .498 Dia x .340 1
37 738-0533 Screw, Shoulder, .498 x 1.635 2
38 738-3056 Bolt, Shoulder 2
39 741-0338 Bearing, Flange, 3/4 ID x .52 LG 2
40 747-3188 Pin, Mower Support 2
41 750-3136 Spacer, .5 OD x .75 x 2.07 Lg 1
42 747-3172B Rod, Front Lift 1
43 712-3048 Nut, Hex Jam, 1/2-13 GR5 2
44 736-0921 Washer, Lock, 1/2 2
45 738-0507B Bolt, Shoulder, .50 Dia. x .494 Lg 2
46 712-3083 Nut, Hex Insert Lock, 1/2-13 2
47 603-0200 Bracket, Front Lift 1
48 777S30145 Graphic, Danger 1
49 736-0226 Washer, Flat, .474 x .88 x .064 6
50 732-3126 Spring, Ext., .91” OD x 7.33 1
44" DECK ASSEMBLY
