Page 33
-33 -
REF.
NO.
PART
NUMBER
DESCRIPTION
QTY.
1
603-0211
Bracket, Grille LH
1
2
603-0212
Bracket, Grille RH
1
3
603-04063
Bracket, Upper Hood
1
4
703-2396
777D03263
777D03272
777X40079
Panel, RH Side
Graphic, Hood RH
Graphic, 2186
Strip, Protective
1
1
1
1
5
703-2397
777D03264
777D03272
777X40079
Panel, LH Side
Graphic, Hood LH
Graphic, 2186
Strip, Protective
1
1
1
1
6
703-2398
777I20314
Grille
Graphic, Warning HOT
1
1
7
703-2465
Link, Short Hood
2
8
703-2466A
Link, Long Hood
2
9
703-2495
Screen, LH Panel
1
10
703-2496
Screen, RH Panel
1
11
710-0351
Screw, Truss Mach Tapp, #10 x .50
8
12
710-0599
Screw, Hex Wash Hd Tapp, 1/4 x .50
6
13
712-3027
Nut, Hex Flange Lock, 1/4-20
8
14
712-3087
Nut, Wing, 1/4-20
2
15
723-3059
Trim, Seal w/Glue
1
16
726-0139
Nut, U-Type Speed, #10
2
17
625-04001
725-0963
725-1649
Headlight Assy (Includes Lamp and Socket)
Lamp, 12V
Socket, Lamp
1
2
2
18
732-0334
Spring, Compression, .50 OD x .50
4
19
732-1178
Spring, Hood Latch
1
20
736-0175
Washer, Spring, .265 x .562 x .025
8
21
736-0400
Washer, Flat, .218 x .62 x .063
2
22
738-3141
Bolt, Shoulder, .31 Dia x .75 Lg
2
23
748-3055
Bushing, Tapered
4
24
959-3747B
Hood, Series 2000
1
GRILLE, HOOD AND SIDE PANELS
